Chassis

Coupling rod

Depending on the construction requirements, the connection rod connects the stabiliser of a vehicle with the chassis of the front axle and/or the rear axle. Together with the stabiliser, connecting rods minimise the vehicle body’s tendency to roll when driving round corners and thus, stabilise the vehicle.

Read more

Hydraulic shock absorber

The hydraulic shock absorber mostly comprises of a cylinder filled with hydraulic oil and a piston, which moves with every vertical movement of the wheel. This piston glides up and down when the...

Read more

Independent suspension

The wheel suspension assumes a crucial role in the vehicle chassis. It establishes the connection between the wheels and the vehicle’s body and transfers all forces and torques between the wheels and bodywork. The wheel suspension is intended to ensure safe driving characteristics and the highest possible comfort. There is a differentiation between independent suspensions, rigid axles and torsion-beam axles.
If the axle in question is a driving axle, it ensures that the driving force from the engine is transferred to the wheels. In addition, the front axle transfers steering motions to the wheels.

Read more

Rigid axle

The wheel suspension is the link between a vehicle’s body and its wheels. Alongside independent suspension and torsion-beam axles, rigid axles are among the most important construction types. Rigid axles are used in commercial vehicles and off-road vehicles due to their robust construction. In cars, they have been almost entirely superseded by independent suspensions (link: independent suspensions).

Read more

Shock absorbers

In recent years, advances in the development of modern vehicles and increasing engine performance and speed in particular have brought about sharp focus on chassis technology as an area of development...

Read more

Single-tube gas-filled shock absorbers

Single-tube gas-filled shock absorbers work along the same principle as a conventional hydraulic shock absorber, but also have a gas cushion that be compressed, therefore creating space for the compressed oil...

Read more

Spring strut support bearings

Spring strut support bearings (also known as tower bearings) are part of the spring damping system, acting as the interface between spring strut and car body. As an important construction element of...

Read more

Stabiliser

The stabiliser is a component of the chassis; it operates as a suspension component when cornering to reduce rolling of the vehicle.

Read more

Suspension link

Suspension links, along with the steering knuckle, wheel bearing, spring and shock absorber, are elements of the wheel suspension. Suspension links absorb the forces resulting from the driving dynamics. The bearings dampen the absorbed forces, which increases driving comfort.

Read more

Suspension spring

Suspension springs are the link between wheels and car body. Their primary task is to compensate uneven road surfaces and thus provide an assurance of high levels of ride comfort. Secondly, they must ensure...

Read more

Torsion-beam rear axle

As load-bearing connections between the wheels and body, the axles assume a key function in the chassis system. The axles transfer all forces and torques between the wheels and vehicle bodywork. There is a differentiation between independent suspensions, rigid axles and torsion-beam axles. In the broadest sense, torsion-beam rear axles are a variant of the rigid axle.

Read more

Wheel bearings

Wheel bearings guide and support shafts and axles. They are part of the chassis, guide the wheels and absorb axial and radial forces. Radial forces are longitudinal forces produced as a result of rotation. They are applied to the wheel bearing at a right angle to the longitudinal axis.

Read more

Wheel carrier

The part of the wheel suspension which supports the wheel bearing is referred to as the wheel carrier.

Read more

Wheel suspension

The wheel suspension is part of the chassis. The chassis comprises the following components: wheels, wheel carrier, wheel bearing, brake, wheel suspension, axle support, suspension (including anti-roll bar)...

Read more
